Deploy LocalStack Operator

Introduction

The LocalStack Operator provides a Kubernetes-native way to deploy and manage LocalStack instances. It abstracts Kubernetes-specific configuration and automates operational tasks, making LocalStack deployments more consistent and easier to maintain.

The Operator manages the full lifecycle of LocalStack resources and enables advanced Kubernetes integrations that are difficult to configure manually.

Getting started

This guide explains how to deploy and manage LocalStack in a Kubernetes cluster using the LocalStack Operator.

Advanced features

The Operator supports the following advanced capabilities:

Cluster DNS configuration to correctly resolve AWS-style subdomains
Automatic loading of Cloud Pods on startup
Support for initialization hooks
Simplified logging configuration
Automatic mounting of a PersistentVolumeClaim (PVC) for the LocalStack data directory, enabling artifact caching and persistence

Prerequisites

Before installing the LocalStack Operator, ensure you have:

A running Kubernetes cluster
A LocalStack license that includes Kubernetes features
An authentication token for that license

Deploy Operator

The easiest way to install the Operator controller is to apply the published manifests directly from GitHub.

# Install the latest version
kubectl apply -f https://github.com/localstack/localstack-operator/releases/latest/download/controller.yaml

To install a specific version:

# Example: install v0.4.0
kubectl apply -f https://github.com/localstack/localstack-operator/releases/v0.4.0/download/controller.yaml

See the Operator releases page for all available versions.

Deploy LocalStack instance

Once the Operator is running, you can deploy a LocalStack instance by creating a LocalStack custom resource.

A minimal example looks like this:

apiVersion: api.localstack.cloud/v1alpha1
kind: LocalStack
metadata:
  name: localstack
  namespace: my-namespace
spec:
  image: localstack/localstack-pro:latest
  dnsProvider: coredns
  dnsConfigName: coredns
  dnsConfigNamespace: kube-system
  envFrom:
    - secretRef:
        name: localstack-auth-token

In this example, the LocalStack auth token is read from a Kubernetes Secret named localstack-auth-token.

You can create this Secret with:

kubectl create secret generic localstack-auth-token \
  --from-literal=LOCALSTACK_AUTH_TOKEN="$LOCALSTACK_AUTH_TOKEN"

The auth token must be available in the LOCALSTACK_AUTH_TOKEN environment variable when creating the Secret.

notes::: More advanced examples are available in the LocalStack Operator GitHub repository. :::

Accessing LocalStack

By default, the Operator creates a ClusterIP Service named:

localstack-<crd-name>

For the example above (name: localstack), the Service name is:

localstack-localstack

This Service exposes:

The LocalStack gateway port (4566)
AWS service ports
Port 53 for DNS

Using standard Kubernetes DNS resolution, the Service can be reached at:

localstack-localstack (same namespace)
localstack-localstack.my-namespace
localstack-localstack.my-namespace.svc.cluster.local

When dnsProvider: coredns is configured, LocalStack can also be reached through any subdomain of these service names.

CRDs

The LocalStack Operator introduces a LocalStack Custom Resource Definition (CRD) that controls how LocalStack instances are deployed and configured.

CRD documentation is currently maintained manually. For a full reference of available fields, see: https://github.com/localstack/localstack-operator/blob/v0.4.0/api-docs.md

Permissions

The Operator manifest creates all required Roles, ClusterRoles, and bindings.

Kind	Name	API Groups	Resources	Verbs
Role	`localstack-operator-leader-election-role`		`configmaps`	get, list, watch, create, update, patch, delete
		`coordination.k8s.io`	`leases`	get, list, watch, create, update, patch, delete
			`events`	create, patch
ClusterRole	`localstack-operator-manager-role`		`configmaps`	delete, get, list, patch, update, watch
			`events`	create, patch
			`pods`, `pods/exec`, `pods/log`	create, delete, deletecollection, get, list, patch, update, watch
			`secrets`	get, list, watch
			`serviceaccounts`	create, delete, get, list, update, watch
			`services`	create, delete, get, list, patch, update, watch
		`api.localstack.cloud`	`localstacks`	create, delete, get, list, patch, update, watch
		`api.localstack.cloud`	`localstacks/finalizers`	update
		`api.localstack.cloud`	`localstacks/status`	get, patch, update
		`apps`	`deployments`	create, delete, get, list, patch, update, watch
		`apps`	`deployments/scale`	create, delete, get, list, patch, update, watch
		`rbac.authorization.k8s.io`	`rolebindings`, `roles`	create, delete, list, update, watch
ClusterRole	`localstack-operator-metrics-reader`		(nonResourceURLs: `/metrics`)	get
ClusterRole	`localstack-operator-proxy-role`	`authentication.k8s.io`	`tokenreviews`	create
		`authorization.k8s.io`	`subjectaccessreviews`	create

Manager ClusterRole

This ClusterRole allows the Operator to manage LocalStack resources and related Kubernetes objects.

Resources include:

Pods (including exec and logs)
Services
Secrets
Deployments
ServiceAccounts
LocalStack CRDs (localstacks, status, finalizers)
RBAC roles and role bindings

Verbs include:

create, delete, get, list, watch, patch, update

Metrics and proxy ClusterRoles

Additional ClusterRoles are created for:

Reading metrics (/metrics)
Authentication and authorization reviews (tokenreviews, subjectaccessreviews)

DNS handling

The LocalStack Operator configures cluster DNS to forward AWS-style subdomain requests to the LocalStack DNS server.

This enables features such as:

S3 virtual-host–style addressing
API Gateway domain name resolution

Example from another pod in the cluster:

aws apigatewayv2 create-api \
  --name testGatewayProxy \
  --protocol-type HTTP \
  --target "https://httpbin.org"

Example response:

{
  "ApiEndpoint": "http://1d4b6907.execute-api.localstack-localstack.my-namespace:4566",
  "ApiId": "1d4b6907"
}

Calling the API:

curl http://1d4b6907.execute-api.localstack-localstack.my-namespace:4566/json

This works without additional DNS configuration in client applications.

Update

The Operator can be upgraded by applying a newer controller manifest.

Example:

# Install an older version
kubectl apply -f https://github.com/localstack/localstack-operator/releases/download/v0.3.3/controller.yaml

# Upgrade to a newer version
kubectl apply -f https://github.com/localstack/localstack-operator/releases/download/v0.4.1/controller.yaml

Kubernetes will handle rolling updates of the Operator deployment.

Verify

To verify that the Operator and LocalStack instance are running:

kubectl get pods -n my-namespace
kubectl get localstacks -n my-namespace

Ensure that:

The Operator controller pod is running
The LocalStack resource reports a healthy status
The LocalStack Service is created
